BD-04 44’x26’8″

”Ma” Williams, manufactured and modular homes

Floor Plan


Floor Plan Specifications

  • 2×6 Transverse Floor Joists-16″ on Center per Plan, with 3/4″ OSB Floor Decking
  • 90″ Sidewall Height with Cathedral Ceilings per Plan
  • Insulation: Ceiling R-22, 2X4 Exterior Wall Studs with R-13 & Floor R-11
  • Dual-Glazed Vinyl low-E Windows
  • 100 Amp Electrical Service
  • 20lb Roof load
  • 30 gallon Gas Water Heater and Down Flow Gas Furnace
  • Cement Fiber Siding
  • Class “A” Architectural Roof Shingles
  • 6-Panel 36″ Vinyl-Covered Insulated Entry Door
  • 6-Panel 32″ Vinyl-Covered Insulated Rear Entry Door
  • 16″ Front Overhang. Side Eaves per Plan
  • Craftsman Style Shutters (per plan)
  • 8″ Hardboard Fascia with 4″ Hardboard Corner & Window Trim
  • 1/2″ Drywall on Walls with Square Corners with Orange Peel Textured Finish on Walls and Ceilings
  • Dramatic Sculptured Passage Door Casings and 3 1/4″ Floor Moldings Throughout
  • Carpeting in Living Areas with 1/2″ Rebond Pad and Vinyl Flooring in Kitchen, Baths, Utility, Nook and Dining Areas per Plan
  • 3-Panel Passage and Wardrobe Doors throughout with Satin Nickel Finish Lever handles
  • Hidden Hinges with Soft Close Feature on Cabinet Doors
  • Toe Kick Resisters in Kitchen and Baths
  • Hand Finished Wood Cabinets Throughout with Solid End Panel Construction
  • 8″ Deep Stainless Steel Self-Rimming Sink with Moen Dual Handle Faucet
  • Whirlpool White Finished Kitchen Appliances
  • Corian Countertops with 4″ Backsplash, 2″ front drop edge
  • 18 Fu Ft Double Door Refrigerator
  • 30″ Gas Freestanding Range
  • 60″ 1-Piece Fiberglass Tub/Shower in Both Master and Guest Bath
  • China Sinks
  • Elongated Water-Saver Commode
  • Satin Nickel Fixtures
  • Vanity Mirror with Beveled Edge Mirrored Medicine Cabinet
  • Towel Bar, Towel Ring & Tissue Holder – Chrome
  • Corian counters with 4″ backsplash

Photos


Floor Plan Description

Model NumberBD-04
Bedrooms3
Bathrooms2
Square Footage1173 SF
Width26'8"
Length44'

The Bradford 04 is available in either a 1041 or 1173 square foot version (it is the same layout only one floorplan is slightly wider than the other). Although the larger version of this home is under 1200 square feet, creatively used space together with an open concept floorplan make the home appear larger than it is. This energy efficient three-bedroom, two-bath home’s split-bedroom style allows for maximum privacy in cozy corridors. Additionally, this home offers a kitchen pantry, a guest closet and an optional hallway linen. You might consider this home as a primary residence, a vacation home, or as an affordable way to place an accessory dwelling unit into your backyard as housing for family members, friends, students, or renters. Small house plans are an affordable choice - they offer lower maintenance costs and do not require much energy to heat and cool. Although the home already features a seven-year Silvershield warranty, hardwood cabinetry, Corian countertops, crown molding, sculpted cased windows and baseboards, etc., you can further customize both the interior and exterior to your liking. Please note both traditional and/or contemporary rooflines are available.

**Floor plan specifications and materials are subject to change without notice or obligation.**
